CE50H3 Angle Roll

00-CE50H3-beauty-shot2

Image 1 of 8

CE50H3 Angle Roll: 2-1/2″ Gas inches (3.6 mm) capacity

Electrical Options:
220V or 480V 3ph

THIS VIDEO SHOWS ERCOLINA’S CE50H3 ANGLE ROLL BENDING 1-1/2″ SCH. 40!

Ercolina’s CE50H3 angle roll model offers hydraulic center roll positioning.

Ercolina’s affordable tube benders and fabricating machines are designed to reliably and accurately produce your bending applications. As a result, our machines will increase profit, as well as improve product quality and finish.

50mm roll shaft diameter
80 x 2 mm round tube capacity
2-1/2″ Gas inches (3.6 mm) capacity
Maximum angle capacity 60 x 60 x 6 mm
Bending speeds 20% faster than competitive machines
Universal tooling set included with each machine – 7″ OD
Forged roll shafts precision ground and fitted for maximum performance and minimal deflection
Heavy duty structure and rigid components for high section modulus ratings
Reinforced engineered mainframe design proven to outperform competitive models
Patented by Ercolina simultaneous downfeed and roll movement to minimize deformation

Programmable touchpad controls with digital center roll positioning display
Hydraulic machine with memory storage with eight (8) individual programs and unlimited passes
Remote pendent with low voltage controls and foot pedal switch
Threaded roll shafts with micrometric flange adjustment helps eliminate spacer usage
Inline direct drive roll shaft system
Optional Anti-twist correction system for angle iron “Leg In” applications
All capacities based on mild grade materials; heavy wall and high tensile materials reduce machine capacity.
