GB100CNC Giga Bender

08_GB100

Image 6 of 8

Request a quote on this mandrel bender or call 519-455-7100, for immediate assistance.

GB100CNC Giga Bender: Tube capacity to 120 x 5.3 mm

Electrical Options:
480V Three Phase

THIS VIDEO HIGHLIGHTS ERCOLINA’S GB100 GIGA BENDER BENDING 3″ – .065 WALL STAINLESS R140!

Ercolina’s GB100SCNCV2 mandrel bender is ideal for industrial mandrel bending tube, pipe, square and rectangular profiles to a center line radius as tight as 1.5 x diameter. Large radii tooling is available to 400 mm CLR.

Ercolina’s affordable tube benders and fabricating machines are designed to reliably and accurately produce your bending applications. As a result, our machines will increase profit, as well as improve product quality and finish.

  • Mild steel tube capacity 120 x 5.3 mm
  • 3″Gas inches (5.3 mm)
  • Square tube capacity 100 x 100 x 3.2 mm
  • A36 pipe capacity to 3″ Sch. 40
  • Interactive PLC touch screen offers easy access to auto and manual operating modes, system diagnostics and multiple language capability
  • GB100CNC control of 7 axis with Windows controller
  • Programmable bend angles with independent material springback setting for each bend
  • Programmable auto mandrel positioning allows operator to optimize extraction for improved bend quality
  • Programmable clamping, pressure die and boost movements with manual override
  • USB for unlimited program memory storage and communication
  • Precision encoders on each axis
  • Touch screen displays absolute (ABS) or incremental (INC) positioning with inch or metric readout
  • Programmable tail stock interference zone monitors position and eliminates workhead collision
  • Standard hydraulic ports accept Ercolina’s patented (KST) clam shell clamp system
  • Accepts YBC and XYZ input values
  • Y – Auto Feeding Hydraulic
  • B – Auto Feeding Hydraulic
  • C – Bending Hydraulic CNC
